Cervelo R5 Red eTap AXS

Cervelo R5 Red eTap AXS
$16,250.00
Color: Five Black
Size: Select size
Please select options Unavailable

Details

R5 has one job-get to the top, fast. But for all the glory and fanfare that comes with a summit finish, they're rarely the only climb of the day. And while a race isn't usually won on a descent, they can certainly be lost. A climbing bike that can't carve a hairpin is a bit like a cup of decaf coffee. This is the fourth iteration of the R5, and while weight and stiffness have varied over the years, the handling, poise, and unmatched prowess on a descent have been consistent since day one.

Geometry

Geometry Chart:
Frame Size485154565861
Reach | mm 363 371 380 389 398 407
Stack | mm 497 522 547 572 597 622
Head Tube Angle 71° 72° 73° 73° 73° 73°
Front Center | mm 574 576 578 594 611 628
Bottom Bracket Drop | mm 74.5 74.5 72 72 69.5 69.5
Head Tube Length | mm 93 114 137 163 192 218
Top Tube Length | mm 515 531 548 564 581 598
Seat Tube Angle 73° 73° 73° 73° 73° 73°
Standover Height | mm 695 724 755 778 800 824
Trail | mm 57.3 57.3 57.3 57.3 57.3 57.3
Wheel Size 700c 700c 700c 700c 700c 700c
Fork Offset | mm 57.5 51.5 45.5 45.5 45.5 45.5
Wheelbase | mm 972 974 977 994 1011 1028
Chainstay Length | mm 410 410 410 410 410 410

Specs

Fork Cervélo All-Carbon, Tapered R5 Fork
Wheels New Reserve 34/37mm DT240 XDR, 24h (F), 24h (R), 22.6mm IW (F), 21.6mm IW (R), Center-Lock, Tubeless Ready
Axles Cervelo Aero Thru-Axles, 12x100/142, Removable Handle
Tires Vittoria Corsa TLR G2.0 25c
Bottom Bracket Ceramic Speed Dub
Crankset SRAM Red AXS 48/35 with Power Meter
Shifters SRAM RED eTap AXS HRD 12 spd
Front Derailleur SRAM RED eTap AXS 12 spd
Rear Derailleur SRAM RED eTap AXS 12 spd
Cassette/Freewheel SRAM RED 12s XG1290, 10-28
Chain SRAM RED 12 spd
Brakes SRAM Red HRD
Handlebars Cervélo HB13 Carbon
Stem Cervélo ST31 Carbon
Headset FSA IS2 1-1/4 x 1-1/2
Seatpost Cervélo SP24 Carbon
Saddle Prologo Scratch M5 NACK OR Selle Italia FLITE BOOST SuperFlow Carbon
Pedals Sold separately
Accessories & Extras Cervelo Handlebar Front Computer/Light Mount, Cervelo Rear Accessory Mount

* Subject to change without notice.

Part Numbers

Option UPC MPN
Five Black / 48cm 042677638032 0H1R5GRX1C48
Five Black / 51cm 042677638056 0H1R5GRX1C51
Five Black / 54cm 042677638070 0H1R5GRX1C54
Five Black / 56cm 042677638094 0H1R5GRX1C56
Five Black / 58cm 042677638117 0H1R5GRX1C58
Five Black / 61cm 042677638131 0H1R5GRX1C61
